Description
F300 Series Sensors adalah sensor kecepatan udara dan suhu udara yang serbaguna, kokoh, dan berkinerja tinggi. Dengan elektronik berlapis konformal dan penutup rapat, area sensor F300 cocok untuk lingkungan korosif atau alkalin. Dengan desain yang kuat, tahan percikan, dan konstruksi tahan UV.
Persyaratan untuk digunakan dengan pencatat data tertentu:
- HOBO MX1100 series: a 0-5 Volt DC input cable (SD-VOLT-05) and external power provided by an AC adapter (AC-SENS-1)
- HOBO U12, UX120-006M, or ZW series: a 0-5 Volt DC input cable (CABLE-ADAP5) and external power provided by an AC adapter (AC-SENS-1)
- HOBO RX3000: an analog input module (RXMOD-A1)
- HOBO U30: an analog input module (VIA)
- HOBO H22: an analog input module (S-FS-CVIA)
Fitur
Menambah kemampuan pengguna untuk dapat mengukur kecepatan udara (dalam saluran, misalnya) dari mana CFM dapat dihitung.
Spesifikasi
| Operating temperature range | 0°C to 60°C (32°F to 140°F) |
| Velocity range | 0.15 to 1.0 m/s (30 to 200 fpm) 0.5 to 10 m/s (100 to 2,000 fpm) 1.0 to 20 m/s (200 to 4,000 fpm) |
| Response time | 400ms |
| Storage temperature | -40°C to 105°C (-40°F – 220°F) |
| Relative humidity (non-condensing) | 5-95% |
| Supply power requirements | 4.5-15 VDC, 35mA nominal |
| Velocity Output | 0-5V |
| Temperature output | 0-5V |
| Housing Construction | Polycarbonate (PC), UL94-V0 (head) UL94-HB (housing) |
| Plenum rated cable | 22 AWG |
| Environmental Protection | IP65 electronics, including conformal coated sensing element |
| Accuracy | 0.15 to 1.0 m/s (30 to 200 fpm): ± (1% of reading + 0.05 m/s [10 fpm]) 0.5 to 10 m/s (100 to 2,000 fpm): ± (4% of reading + 0.10 m/s [20 fpm]) 1.0 to 20 m/s (200 to 4,000 fpm): ± (5% of reading + 0.15 m/s [30 fpm]) |
| Sensor Length | 152mm [6.0”] |
| Max insertion depth | 110 mm [4.3”] |
